Bus Bar


Bus Bar

Bus Bar Grade - Bb 100
We are a foremost Electrical Insulation Sleeve manufacturer catering sleeves to insulate Electrical Bus Bars & Conductors across the globe with a unique identity established over a period of time with consistent performance.

“Shrinkin'Sleeves" used to Insulate “Bus Bars and Conductors” provide excellent insulation with a High Dielectric Strength & a Good Retention of Dielectric Strength under Wet Conditions

Physical & Electrical Properties
  • Tensile Strength : > 300 kg/Sq. Cm.
  • Ultimate Elongation : > 250 %
  • Insulation Resistance : 3 x 106Mega ohms (at R/T)
  • Dielectric Strength : 12 KV ( B.D.V. : 15 KV )
  • Shrink Temperature : 120o Centigrade
  • Shrink Ratio : MD - 10 % TD - 40 %
  • Continuous Operating Tempt : - 05 to 1100 Centigrade
  • Corrosive effect - Non Corrosive : Resistant to acid, alkalis & oil
  • Fire Retardation : Self extinguishing, Non flammable
  • Type : Creased type
  • Sizes Available : L/F size 41mm to 240 MM
  • Bus Bars Size : 25 x 6 to 200 x 12 MM
  • Thickness : 0.20 to 0.40 MM
  • Std. Color : Red, Yellow, Blue & Black
  • Std. Length / Roll : 50 to 100 meters
  • Shelf Life : 6 months, stored below 25o Centigrade
